On the opposite side of the timing cover you will see two diagonal bolts.. Right above them is a small round machined surface with a little hole in the center.. That is where the old style pointer would be..
What does a timing pointer do?
A timing mark is an indicator used for setting the timing of the ignition system of an engine, typically found on the crankshaft pulley (as pictured) or the flywheel, being the largest radius rotating at crankshaft speed and therefore the place where marks at one degree intervals will be farthest apart.
How do you advance timing on a Ford 302?
For an initial start, it is recommended that you advance the timing by turning the distributor counter clockwise 10°, and then set the timing by using a timing light.
What can I use to mark a timing chain?
Paint marker is great. But in a pinch I’ve also used white-out. Just a quick shot with brake cleaner and let it dry before marking it and it’ll stick.
Which way do I turn my Ford distributor to advance timing?
Turn the distributor in a counterclockwise direction to advance the ignition timing. Do not over-adjust the distributor, as even a slight movement will yield a significant change in the ignition timing.
What happens if your timing is too advanced?
Overheating. If ignition timing is too far advanced, it will cause the fuel-and-air mixture to ignite too early in the combustion cycle. This can cause the amount of heat generated by the combustion process to increase and lead to overheating of the engine.
What is the size of the timing pointer?
Timing Pointer, 6.00 – 6.75 in. Harmonic Balancer Diameter, Billet Aluminum, Natural, Ford, Small Block, Each Timing Pointer, Aluminum, Black Anodized, 11 O’Clock Pointer, Ford, Small Block, Each
What is the total timing on a Ford 302?
Some enthusiasts say that a standard total timing (initial timing plus advance) is 34°, others will say 38°, and you will just need to find what works best for your motor. Ford 302 Timing Setting Instructions Set the engine to Top Dead Center. (If you need help finding TDC, check out this guide)
What is the pointer size on a 302?
R, he said it’s a mid-’70s 302, making it a left (driver’s) side pump inlet. That would then require a 10 or 11:00 pointer, and that would be based on his aftermarket balancer markings.
How do you set the timing on a small block Ford Motor?
NOTE: Small block Ford rotors always turn counter-clockwise. Let the motor get up to operating temperature, and then use a timing light to set the timing between 34°-38°total timing, again you will need to find what works best for your motor.
