Pipe Hangers and Supports
MSS SP-58 – Manufacturers Standardization Society: Pipe Hangers and Supports – Materials, Design, and Manufacture. F. MSS SP-69 – Manufacturers Standardization Society: Pipe Hangers and Supports – Selection and Application.
What is a trapeze hanger?
What is a trapeze hanger? The trapeze hanger is a classic example of a strut-based pipe hanging solution. Typically constructed using 41×41 strut and lengths of threaded rod, these supports can be suspended from ceilings or steel beams to provide support for pipes and cable trays.
What is a clevis hanger?
Clevis hangers are pipe supports that are designed to secure hanging or elevated pipe runs. If you need to suspend piping from elevated beams or the ceiling, clevis hangers are a lifesaver. Generally, clevis hangers include a yoke that connects to your support overhead.
What are MSS standards?
MSS standards address requirements for process piping in the petroleum, petrochemical, food, beverage and utility industries for products such as valves, pipe fittings, flanges and seals. These industry standards help you: Promote interoperability. Ensure quality.
What is loop hanger?
A loop hanger is a pipe accessory that loops around a pipe in order to support it. Loop hangers are similar to clevis hangers, split ring hangers, and clamp hangers, which are all examples of pipe hangers, but there are qualities that help to set loop hangers apart from the rest.
How much weight can a clevis hanger hold?
Fig. 83: Adjustable Clevis Hanger
| PIPE SIZE | MAX. RECOM. LOAD, lbs. | SIZE OF STEEL |
|---|---|---|
| 10 | 3600 | 3/8 x 1 3/4 |
| 12 | 3800 | 3/8 x 2 |
| 14 | 4200 | 1/2 x 2 |
| 16 | 4600 | 1/2 x 2 1/2 |
What is MSS SP-58?
MSS SP-58 is the set of guidelines and fabrication criteria for pipe hanger components to ensure pipes maintain the combined weight of the pipe system and the material that passes through it.
What are The SP-58 standards for pipe supports and hangers?
MSS SP-58 standards clarify what materials should be used to construct pipe supports and hangers. Materials for fabrication include copper, steel, glass, and plastic; however, each of these materials has its own standards and must meet all the requirements for strength and durability, depending on their use.
What is ansansi sp-58-2018?
ANSI/MSS SP-58-2018 covers many different materials that pipes might be made out of, including, but not limited to, copper, steel, glass, and plastic. There are different specifications of pipe hangers and support based on these materials.
What is the MSS standard practice?
This MSS Standard Pracîice was developed under the consensus of the Technical Committee 403 and the MSS Coordinating Commiüee. The content of this Standard Practice is the resuit of the efforts of competent and concerned volunteers to provide an effective, clear, and nonexclusive specification that will benefit the industry as a whole.
