To use a Trimble® SketchUp® design in Revit, you can import a SKP file from Trimble® SketchUp® directly into Revit. As an alternative, you can use Trimble® SketchUp® to export a DWG file, and then import that DWG file into Revit. You could also link a SKP file to the Revit project, instead of importing it.

How do I link SketchUp to Revit?

Import SketchUp Files

  1. Create a family in the Family Editor.
  2. Click Insert tab Import panel (Import CAD).
  3. In the Import CAD Formats dialog, navigate to the folder that contains the SKP file.
  4. For Files of Type, select the SKP file type.
  5. Select the file to import.
  6. Specify the desired import settings.
  7. Click Open.

How do you explode a Revit model in SketchUp?

Because of the way Sketchup files are imported into Revit, they behave differently when exploded. The model will have to be exploded twice to effect a visible change. Select the import symbol. Click Modify | tab Import Instance panel Explode drop-down (Partial Explode) or (Full Explode).

How do I use rvt2skp?

Yes! rvt2skp comes with a free trial of one (1) export. At the end of the trial, you may purchase a rvt2skp license.

What is the difference between Revit and SketchUp?

Revit belongs to the family of BIM software. Sketchup, however, is a CAD software. BIM software is used for design, infrastructure design, and documentation. Thanks to BIM software, you can visualize how your project will look like in real life, test different design solutions, and generate construction documentation.

How do I open a Revit file?

To open a Revit file, use any of the following methods:

  1. Press CTRL+O .
  2. On the Home page, under Models or Families, click Open, or click a thumbnail image in the Recent Files list.
  3. Click File tab (Open).
  4. Click File tab (Open), and select a file type.
  5. Click File tab, and select a file from the Recent Documents list.

How do I import SketchUp into AutoCAD?

The following steps walk you through the import process for your operating system:

  1. In SketchUp, open the SketchUp model into which you want to import your .
  2. Select File > Import.
  3. Navigate the the place your hard drive where your CAD file is saved.
  4. From the Files of Type drop-down list, select AutoCAD Files (*.

How do I export a Revit model?

To export 3D model data for use in Autodesk Revit

  1. Click Manage Model.
  2. In the Model Explorer panel, make the desired layers visible.
  3. Zoom out to see the area to export.
  4. Click Present/Share Present.
  5. In the Export to 3D Model File dialog box, specify the area to export:

How do I export materials in Revit?

Click the Manage Ribbon Tab. Select the Transfer Project Standards command on the Settings Ribbon Panel. Check the box for Materials. Click OK.

Can you convert a Revit file to AutoCAD?

Just in case you need to convert a 3D Revit model to 3D AutoCAD, here ya go. With the Revit model open, Click the Application Menu (“Big R”) > “Export” > “CAD Formats” > Select “DWG“. In the “DWG Export” dialog box – Click on the ellipsis (button with 3 dots) to open the “Modify DWG/DXF Export Setup” dialog box.

How do I import AutoCAD into SketchUp?

Importing a CAD file into SketchUp

  1. In SketchUp, open the SketchUp model into which you want to import your .
  2. Select File > Import.
  3. Navigate the the place your hard drive where your CAD file is saved.
  4. From the Files of Type drop-down list, select AutoCAD Files (*.
  5. Select the file you want to import.

¿Cómo utilizar los elementos de SketchUp en Revit?

Para poder utilizar los elementos y bloques de Sketchup en Revit debes realizar los siguientes pasos: Paso 2: Damos click en Archivo > Guardar como > *Elegimos la versión de Sketchup 6* Paso 5: Abrir el proyecto donde queremos importar el modelo o crear un proyecto nuevo

¿Cómo exportar a SketchUp?

Sigue estos pasos sencillos y aprende como exportar de Revit a SketchUp. Lo que primero debes hacer, es abrir el archivo en Revit que deseas exportar, así como lo puedes ver en la siguiente imagen: Después debes hacer que el modelo a exportar sea compatible y no tengas que hacer modelados adicionales.

¿Cómo guardar un archivo en formato de SketchUp?

Para finalizar tienes que darle File>Save y guardar tu archivo en formato de SketchUp, este programa te ofrece muchas herramientas para modelar fácilmente. Además de la visualización desde diferentes perspectivas, conoces todas las funciones, práctica y aprende usándolo, con la interfaz sencilla y crea todo lo que tu mente quiera.
